12.96kW DIY Solar Grid-Tie Kit | Micro-Inverter & Racking System

🌞 Product Overview

Optimize your solar investment and create a more resilient energy future with our 12.96kW DIY Solar Grid-Tie Kit. Designed for easy installation, this kit is perfect for homeowners seeking a reliable, high-efficiency solar solution. Complete DIY installation guidance is provided according to your project requirements.

🔍 Virtual Site Inspection

We provide custom design plans for your site. Plans are guaranteed to be approved by city and utility departments. Revisions are included at no extra cost until approval from all jurisdictions.

• If an engineering structure letter or stamp is required, it can be provided for $200–$600.

📦 This System Includes

• Luxen Solar DIY Module
• Half Cell, Bifacial, Single Glass Module – up to 30% extra power generation from the back side
• Black-on-Black Modules (perfect for your roof)
• Micro-Inverter (four panels per inverter)
• Wi-Fi Cloud Monitoring System
• Racking System with attachments
• PV Cable & Connectors, Micro-Inverter Cabling & Connectors
• Utility Disconnect Box
• Grid Tie-In Connectors & Roof Junction Box (according to plan set)

⚙️ Additional Equipment Required

For home run wiring (from array to main service panel or meter), use:

• Wiring: AWG 10 or 8
• Conduit: ¾-inch or 1-inch EMT, PVC, or Flex Liquid Tight

🛡️ Panel Warranty & Certification

• 25-Year Warranty for Materials and Processing
• 25-Year Warranty for Extra Linear Power Output
• Certifications: IEC 61215, IEC 61730, UL 1703, UL 61730, IEC 62804 (PID), IEC 62716 (Ammonia Resistance), IEC 61701 (Salt Mist Level 6), ISO 9001:2015, ISO 14001:2004, OHSAS 18001:2007

🏗️ Racking System

Components are tested in extreme environments for superior structural performance. Fully certified with unique structural features for lasting durability and safety.

• Integrated Grounding (UL 2703) – eliminates separate module grounding components.
• Class A Fire Rating – maintains roof fire resistance
• 20-Year Warranty – twice the protection offered by competitors
• PE Certified – pre-stamped engineering letters available in most states

⚡ Micro-Inverter

4-in-1 microinverters deliver safety, stability, and high efficiency. Supporting up to four panels per unit, they maximize PV production and are one of the most cost-effective module-level solar solutions.

• Operates on <60V DC voltage with 6,000V surge protection
• IP67 Enclosure – weatherproof and durable
• Cloud Monitoring with individual panel-level tracking
• Early detection of potential problems ensures 24/7 property safety
• Easy plug-and-play installation
• Reactive power control, compliant with CA Rule 21
• Compliant with U.S. NEC 2017 & NEC 2020 690.12 Rapid Shutdown
• Up to 25-Year Warranty

💬 Note

For custom system quantities or configurations, please contact us directly for expert support and tailored solutions.
